BOXSTREAM 1450 V2P
Fully Automatic E-commerce & Ice-Cream Box Making Machine

Servo Feeding Unit

Servo motor drive, pressure-free vacuum adsorption type lead edge feeder system.

• Servo motor pressure-free vacuum adsorption wheel-type front edge feeder for fast paper feeding, high efficiency, high precision and stable, smooth feeding of warped boards
• High feeding precision; suitable board thickness 1.5–11 mm
• Mechanical vibration is largely eliminated, avoiding vibration from cam transmissions and minimizing clearance error during pull-wheel operation
• Left/right and back baffles set on touch screen — electronically and digitally controlled — with side squaring installed for precise feeding
• Can run continuous paper feeding or skip feeding
• Auto-zeroing: feeder and printer are fitted with auto-zeroing devices so all units share a unified setting reference, minimizing blank waste
• Dust removal: dedicated dust-removing unit on the feeding station for reliable high-screen and large-field printing
• Tracking display screen: 23.5-inch color display on the feeder unit plus a machine-back-side imaging display monitor on the die-cutting unit, for clear observation of machine operation
• Operation controlled from both the main console and each unit's touch screen
• Lead-edge feeding with adjustable air control and precise registration
• Precision linear guideway lateral moving mechanism
• Motorized side squaring and paper support
• Powerful dust remover with anti-static bar and centralized dust collection for less ECT loss

Bottom Printing Unit (Two Units / Colors)

• Vacuum transfer with independent servo phase control on every unit, synchronizing printing and impression for sharp, clean images with simple design and easy maintenance; order storage via touch screen
• Precise setting system regulating impression and ink-supply gaps
• Variable-frequency electric operating system — one-button roller-gap control from the touch screen
• High printing registration accuracy: ≤ ±0.25 mm
• Printing plate cylinder: quality steel, dynamically/statically balance-tested and precisely milled, with longitudinal/lateral surface grooves for plate mounting, chrome-plated for durability, 10 mm plate-attaching strip with ratchet wheel, roller correcting device for inclined printing, circumferential adjustment on touch screen with ±10 mm shifting range
• Vacuum transfer case: seamless precisely-machined cylinder, chrome-plated and sand-blasted; impression cylinder static- and dynamic-balance tested; Japanese precision roller bearings on cage-roll shafts; multi-point oiling system; touch-screen electrical control of elevation clearance and fan air flow (frequency-inverter controlled) for pressure-free feeding that protects blank edges
• Anilox cylinder: 2 sets of ceramic anilox cylinders (250–600 LPI) matched with 2 sets of quality doctor blades; adjustable rubber-roller/anilox clearance with micro-setting for quick adjustment and blade change; dual-directional membrane ink pump with settable ink volume; quick-clean ink chamber; imported ink reversing valve saves water and ink
• Water and ink cycle: dual-directional membrane ink pump supplies ink
• Printing phase positioning device: servo independent control with separate memory and automatic reset
• Operation controlled from both the main console and each unit's touch screen; top-print, high-precision transfer structure with ceramic vacuum transfer wheel for good registration accuracy; quick printing-plate mounting with motorized phase zero; ink-saving circulation system with safety ink-level alarm

Rotary Die-Cutting Unit (Independent Servo Drive)

• Control panel: die-cutter cylinder thickness 20 mm; phase and axial settings, and all clearance settings, are electrically set and digitally controlled from the touch screen; phase control via independent servo system
• Die-cutter cylinder (bottom cylinder): 55 mm thickness, quality-steel construction, precisely machined with dynamic/static balance tests for sound running and accurate cutting; fastening screw-hole spacing 50 mm axial / 20 divisions radial; independent servo motor direct control with fine-tuning during operation; left/right shifting set electrically on touch screen (10 mm range)
• Anvil cylinder (upper cylinder): precisely machined quality steel with dynamic/static balance testing; wrapped with original imported Taiwan Maxdure anvil cover for easy change and long service life; electrically set die-cutter/anvil gap; compensating differential mechanism (±3 mm range); mechanical stretch and lateral movement ±20 mm with overload protector
• Differential compensation device: automatically compensates the linear-speed change produced by the repaired roller after repair, ensuring die-cutting accuracy
• Independent drive system: Germany KEB servo controller and motor
• Air-duct chip blowing plus brush removal effectively strips die-cutting waste; strapping conveyor belt transfers slotting/die-cutting waste out of the machine
• Operation controlled from both the main console and each unit's touch screen; pneumatic self-locking die-cutting roll for smooth die-cutting; C.U.E. quick-change die-cut anvil with grinding mechanism; precise table-speed difference compensation for die-cutting accuracy

Independent Control Cabinet

• Windows-based CNC control system
• Large order-saving memory with trouble-shooting support
• Optimized order memory — store and quickly change orders
• Production and order management — enter box parameters to realize one-key order adjustment of the whole machine
• Can connect to the customer's internal ERP production management system

Stability Unit (Patent Applied)

• Prevents flute collapse: correct pressure keeps flutes from being crushed or collapsing during formation, protecting board quality
• Ensures high-quality boxes and an efficient manufacturing process
• Final squaring: corrects any fishtailing or uneven folding from the folding section — guides and belts align all panels at a true 90° angle before the glue fully sets

Folding & Gluing Station

Folds and glues cartons on both sides of the machine, with bottom-lock attachment and electronic batch counter included as standard.

Folding Station Features

1. Unit-type structure that can work in conjunction with other functional structures
2. Host controlled through a human interface with a wireless remote device for operational flexibility
3. Easily replaceable outsourcing-packed belts — belt changes possible without disassembling shafts in most sections
4. Standard accessories included for A & B-type straight-line cartons
5. FASTRACK Time Dissolver at the final folding section — reduces the roughly 2-hour daily downtime during changeover between two-track and three-track folding jobs
6. All conveyors in the machine can be adjusted by motor
7. Longer folding and closing section allows corrugated cartons to fold smoothly, minimizing the fishtail issue
8. Clapping device at the trombone section prevents fishtail or cross-pasting issues in low-height self-lock and disproportionate cartons
9. Batch counter equipped with an electronic sensor
10. Delivery section adjustable backward/forward and up/down as per carton design
11. Conveyor pressure adjustable pneumatically
