Excellence Series Automatic Folder GluerMachine –
1450PC, 1650PC, 2000PC, 2400PC
- Motorized Inner Conveyors – It helps to save make ready time by 15 to 20% compared to traditional method.
- Unique Auto Removal Central Conveyor – This device saves a huge time in job changeover from bigger size (Three Tracks Jobs) to smaller size (Two Tracks Jobs), this feature directly saves 2-hour time for production compared to other available options in market.
- Clapping Device with Up/Down Delivery Conveyor – This feature helps to run low height short & wide self-lock /disproportionate corrugated cartons like shoe box, electronics boxes, pharma outer cartons. It avoids cross pasting and fish tail issues.
- Pneumatic Squaring Device – It helps to run low height short & wide crash lock corrugated cartons and disproportionate cartons without any cross-pasting issue.
- Independent AC motor for Trombone Section – It helps to enhance productivity by 20 to 25%.
- Pneumatic Upper Carrier Adjustment System – Upper carrier conveyor can be adjusted upward pneumatically.
Key Features:
Technical Specification:
Key Features:
Feeder Section:
- 10 No’s of feeding belts along with 4 suction belts.
- Each feeder belt can be adjusted independently.
- Equipped with adjustable feeding knives – 3 No’s.
- Equipped with pneumatic vibrator – 1 No’s
- Suction System – 1 Set
- Motorized friction feeder with independent ac motor.
- Equipped with led screen to monitor carton delivery at conveyor.
- Getting the feed right is the key to fast and accurate folding: Sets in 25% of the time compare to others, cut down make ready time.
Aligner Section:
Independent part could guide the paper box to a parallel handrail that allows a perfect blank alignment:
- Correct deviation
- Can register to left or right depending of box.
- It helps to minimize the waste and reduce machine stoppage due to error in carton which comes from feeder.
- Perfect folding quality throughout the year.
Pre-Folding Section:
With so much of today’s carton production bring destined for auto erection lines, ensuring accurate, reliable opening of your finished products has never been more important.
- Long pre-folder
- Extra wide lower left-hand belt
- 1st crease pre-folding 180 degrees
- 3rd crease pre-folding 135 degrees
- Equipped with NITTA folding belts
- Standard accessories for b-type folding carton
- Unique design protects the box surface
Pneumatic Upper Carrier Adjustment System:
Upper carrier conveyor can be adjusted upward pneumatically.
4&6 Corner Device: (OPTIONAL)
The hook system is driven by servos controlling system with photoelectric sensors to achieve back folding function. It has high precision and good efficiency.
Crash Lock Section:
- 4 set of folding fingers to fold flaps and panels.
- Three upper & lower carrier
- Standard accessories for b-type crash lock cartons.
Glue Section:
- Excellence series equipped with standard left/right side gluing tank.
- Equipped with advance gluing tank with unique scrapper device with micro-metric adjustment for precise gluing.
- Easy to remove all equipment for quick cleaning.
- Standard 6mm glue disc (optional glue disc width 8,10mm).
- Upper gluing can be done with electronics glue guns, available as optional.
Folding & Closing Section:
Special long folding section, boxes can be well folded and formed in this section.
- Inner couriers are adjusted by motors.
- Smooth and accurate folding of 2nd & 4th
- Three set of upper and lower carrier, they are drive, middle and control side of machine.
- Middle up/down carriers will be lifted up/down by pneumatic system.
- Left and right outward folding belts speed can be micro adjusted to increase folding accuracy.
- Longer folding section, boxes can be well folded and formed in this section.
- Equipped with branded folding belts, NITTA folding belts.
- Main motor controlled by frequency speed variation.
Trombone Section:
- Equipped with independent AC motor.
- Upper & lower drive mechanism for box length adjustment.
- Equipped with automatic belt tension adjusting system.
- Upper arm set can be adjusted backward and forward to ensure a continuous and automatic box collection mechanism.
- Equipped with a control screen for operating the machine.
- Single and easy operation for upper, down expansion adjustment, left or right twin board moveable for piling.
- Batch counter equipped with electronic sensor.
- Standard clapping squaring device used for corrugated cartons.
- Standard finger attachment in trombone section to reduce the cross pasting in lock bottom boxes.
Delivery Section:
This section runs more slowly. Here the shingled stream of cartons moves between two rotating compression aprons so the glue can bond under a precisely set pressure, even at high machine speeds.
- Independent and motorized section.
- Delivery can be adjusted upward & downward depending on box design.
- Upper conveyor can be moved forward and backward, depending on the box length.
- Conveyor pressure can be adjusted pneumatically.
- Standard conveyor squaring device used for crash lock boxes squaring.
- With new structure, it can run automatically with accountable sensor pile the boxes for high efficiency.
- Longer delivery length 6.3 meter with 5.2-meter effective pressing length.
Technical Specification:
SPECIFICATIONS | EXCELLENCE SERIES’ FG-1450PC | EXCELLENCE SERIES’ FG-1650PC | EXCELLENCE SERIES’ FG-2000PC | EXCELLENCE SERIES’ FG-2400PC |
Max. Sheet Size | 1450 X 1200 mm | 1650 X 1200 mm | 2000 X 1400 mm | 2400 X 1200 mm |
Min. Sheet Size | 350 X 350 mm | 350 X 350 mm | 450 X 350 mm | 350 X 350 mm |
Paper Thickness | Cardboard: 200-800 GSM Corrugated Board: N/E/F/AB/A/B/C | Cardboard: 200-800 GSM Corrugated Board: N/E/F/AB/A/B/C | Cardboard: 200-800 GSM Corrugated Board: N/E/F/AB/A/B/C | Cardboard: 200-800 GSM Corrugated Board: N/E/F/AB/A/B/C |
Jobs Can Run | Straight Line, Self-Lock, Crash Lock, Double Wall | Straight Line, Self-Lock, Crash Lock, Double Wall | Straight Line, Self-Lock, Crash Lock, Double Wall | Straight Line, Self-Lock, Crash Lock, Double Wall |
Max. Machine Speed | 300 m/min | 300 m/min | 300 m/min | 300 m/min |
Power Required | 24 kW | 26 kW | 26 kW | 24 kW |
Max. Air Displacement | 0.7m3/min | 0.7m3/min | 0.7m3/min | 0.7m3/min |
Total Weight (In Tons) | 9.5 | 10.5 | 11 | 11.5 |
Machine Dimensions (LXWXH) | 22.1 X 2.1 X 1.9 mtr. | 22.1 X 2.3 X 1.9 mtr. | 22.1 X 2.65 X 1.9 mtr. | 22.1 X 3.05 X 1.9 mtr. |
Technical Specification:
SPECIFICATIONS | EXCELLENCE SERIES’ FG-1450PC | EXCELLENCE SERIES’ FG-1650PC | EXCELLENCE SERIES’ FG-2000PC | EXCELLENCE SERIES’ FG-2400PC |
---|---|---|---|---|
Max. Sheet Size | 1450 X 1200 mm | 1650 X 1200 mm | 2000 X 1400 mm | 2400 X 1200 mm |
Min. Sheet Size | 350 X 350 mm | 350 X 350 mm | 450 X 350 mm | 350 X 350 mm |
Paper Thickness | Cardboard: 200-800 GSM Corrugated Board: N/E/F/AB/A/B/C | Cardboard: 200-800 GSM Corrugated Board: N/E/F/AB/A/B/C | Cardboard: 200-800 GSM Corrugated Board: N/E/F/AB/A/B/C | Cardboard: 200-800 GSM Corrugated Board: N/E/F/AB/A/B/C |
Jobs Can Run | Straight Line, Self-Lock, Crash Lock, Double Wall | Straight Line, Self-Lock, Crash Lock, Double Wall | Straight Line, Self-Lock, Crash Lock, Double Wall | Straight Line, Self-Lock, Crash Lock, Double Wall |
Max. Machine Speed | 300 m/min | 300 m/min | 300 m/min | 300 m/min |
Power Required | 24 kW | 26 kW | 26 kW | 24 kW |
Max. Air Displacement | 0.7m3/min | 0.7m3/min | 0.7m3/min | 0.7m3/min |
Total Weight (In Tons) | 9.5 | 10.5 | 11 | 11.5 |
Machine Dimensions (LXWXH) | 22.1 X 2.1 X 1.9 mtr. | 22.1 X 2.3 X 1.9 mtr. | 22.1 X 2.65 X 1.9 mtr. | 22.1 X 2.65 X 1.9 mtr. |
